Flasher

Flasher

UART driver for flashing ESP32 family μmicontrollers firmare. Works nicely with NVS.

Flasher is desktop port of a ESP-Flasher it supports STUB, and uploads; Application (App), Bootloader (Boot), Partition (Part), Non Volatile Storage (NVS). It really works nicely with the NVS library, because you can generate a in memory NVS partition and upload it to a device. This means in a production line you could easily upload unique data like a serial number, cryptographic certificates to individual units withouth calling a python script.

bin_file_t binfile;

binfile.app.filepath    = "/Users/charrlie/BINARIES/ESP32-C3/app.bin";
binfile.boot.filepath   = "/Users/charrlie/BINARIES/ESP32-C3/boot.bin";
binfile.part.filepath   = "/Users/charrlie/BINARIES/ESP32-C3/part.bin";
binfile.nvs.filepath    = "/Users/charrlie/Binaries/ESP32-C3/nvs.bin";

SerialPort_t Port;

serial_loader_port_osx_init(SERIAL_DEVICE_5, DEFAULT_BAUD_RATE);

if(connect_to_target(ESP32C3_CHIP, HIGHER_BAUD_RATE) == ESP_LOADER_SUCCESS)
{
    get_binaries(ESP32C3_CHIP, &binfile);
    print_bin_info(&binfile);

    flash_binary(binfile.boot.data, binfile.boot.size, binfile.boot.addr);
    flash_binary(binfile.part.data, binfile.part.size, binfile.part.addr);
    flash_binary(binfile.app.data,  binfile.app.size,  binfile.app.addr);
    flash_binary(binfile.nvs.data,  binfile.nvs.size,  binfile.nvs.addr);

    printf("Uploading complete!\n");
    esp_loader_reset_target();
    serial_loader_port_deinit(&Port);
}
